Böhler Core 210 Elektrodesvejser 230 V

Varenr. 7899560

Böhler Core MMA 210A: Én-faset elektrodesvejsemaskine.

Enhed

STK

General
Welding process	MMA - MMA Pulsed - TIG DC Lift - TIG DC Lift Spot Welding
Materials	Carbon steels - Stainless Steels - Aluminum - Cast irons
Dimensions	429x172x316 mm
Weight	9.5 kg
Power supply
Voltage (50/60 Hz)	1x230Vac±15%	1x115Vac±15%
Maximum input power	7.36 kVA	3.74 kVA
Maximum input current	32A	27A
Efficiency	87.3 %	84.6 %
Open circuit voltage	76Vdc
IP protection rate	IP23S
Insulation class	H
Power supply cable	3x2.5mm² - 3m
PFC	yes
Welding
Adjustment range	20A - 210A	20A - 110A
Duty cycle MMA - 40 °C	25% - 210A 60% - 135A 100% - 105A	25% - 140A 60% - 90A 100% - 70A
Function VRD	yes
Remote Control compatible	yes
Welding Parameter Storage	5

Varenr.: 7899560 Kategorier:

Böhler Core MMA 185A: Én-faset elektrodesvejsemaskine.
